ESD Blister

Specially designed for the electronics industry, ESD (Electrostatic Discharge) blister packaging provides protection against static electricity discharge that may occur during the production, transport, and storage processes of sensitive electronic components. These packages are manufactured using conductive or antistatic PS, PET, and PP materials with controlled surface resistance. The ESD materials used ensure that the static charge is dissipated and neutralized in a controlled manner, thereby eliminating risks arising from the triboelectric effect. ESD blisters are an ideal solution for the safe transport, classification, and production line handling of chips, SMD components, Printed Circuit Boards (PCBs), sensors, micro-elements, and high-precision electronic parts. Designed to operate in compliance with EPA (ESD Protected Area) standards, our products provide full integration into both manual and automated production systems. By preventing static accumulation, ESD blister packaging helps protect electronic components from critical production problems such as discharge damage, latent ESD defects, surface burns, micro-circuit breakage, and data corruption. Consequently, this increases product safety and significantly reduces failure and return rates on production lines.
